| Frequency range | UHF 500 - 960 MHz |
| Bandwidth | 25 MHz |
| Preset frequencies | 100 |
| Microphone type | Uni-directional condenser |
| Impedance | 680Ω |
| Max power output (Country Specific) | Configurable upto (35mW) |
| Max input SPL | 100dB for 1% T.H.D |
| Peak deviation | ± 40 KHz |
| Sensitivity | -50dB±3dB |
| Spurious emission | 60 dB below carrier |
| Dynamic range | 110 dB(A) |
| T.H.D. | 0.5% |
| Audio connector | Balanced XLR for MIC out or AUX in |
| Power supply | 6V DC |
| Battery | AA x2 |
| Operating time | about 12 hours |
| Dimensions (mm) | 111 x 148 x 50 |
| Weight (g) | 645 |
Compatible
DWS-612
UHF Dual-Channel, True Diversity Professional Wireless Microphone System
DWS-611
UHF Single-Channel, True Diversity Professional Wireless Microphone System
DWS-602
UHF Dual-Channel, Professional Wireless Microphone System
DWS-601
UHF Single-Channel, Professional Wireless Microphone System
DWS-804
UHF Quad-Channel Modular Chassis, True Diversity Professional Wireless Receiver
DWS-802
UHF Dual-Channel Modular Chassis, Multi-Functional Professional Wireless System
