FUNCTIONS
· The system delivers uncompressed audio with high fidelity across a frequency range of 20Hz to 20kHz using professional-grade microphones.
· It employs full-digital transmission and processing technology to ensure superior sound quality.
· The system uses 128-bit digital encryption, WPA2 secure connections, MAC address filtering, and SSL security to prevent unauthorized access and eavesdropping.
· It supports simultaneous operation of up to six wireless microphones for seamless audio performance.
· The system includes RS485, RS232, and IP communication interfaces for transmitting PELCO and VISCA protocols.
· It enables automatic camera tracking when integrated with compatible cameras and video switchers.
· A built-in high-fidelity speaker automatically mutes when the microphone is activated, preventing audio feedback and ensuring a smooth audio experience.
| Model | DCS-DWVC | DCS-DWVD |
| Power | 100V / 240V AC |
| power consumption | 12W |
| Maximum power consumption | 150W |
| Frequency Response | 20Hz ~ 20KHz |
| Noise ratio | 96dBA |
| Total harmonic distortion | 0.05% |
| Channel Crosstalk | 85dB |
| Dynamic range | 94dB |
| Ethernet control | RJ45 connected to PC |
| Dimensions (mm | 483L x 260W x43.6H |
| Weight | 3kg |
