FEATURES
· The product features a compact, square design with a modern, low-profile structure.
· It is ideal for placement in front of a speaking individual.
· The microphone offers long-distance voice pickup capability, up to 80cm, ensuring clear sound capture.
· It is equipped with both digital and analog outputs, providing reliable backup.
· The dual outputs prevent any audio transmission disruption in the event of a fault in one audio line.
· The microphone includes ON/OFF light indicators on both sides for easy monitoring.
· It is highly adjustable, allowing for a 4-direction angle change.
· The microphone allows for 90° rotation from left to right and a 120° tilt from up to down.
· This ensures optimal positioning for diverse environments.
| Model | DCS-MDA |
| Directivity | Cardioid |
| Sensitivity | -37dB+/-3dB@1KHz (0dB=1V/Pa) |
| Frequency response | 60Hz~17KHz |
| Mic Capsule | 2 |
| Input impedance | 200 Ohms |
| The maximum sound pressure | 125dB at 1KHz 1% T.H.D |
| Power supply | 9-48V Phantom Power |
| External interface | 6-pin/XLR |
| Size | 36*24*216 (mm) WxHxL |
| Weight | 180g |
| Color | Matte black |
